Water System Schematic
by 3DWarehouse
Last crawled date: 4 years, 8 months ago
Typical municipal water system with: - Source: Pump in aquifer or water source - Storage: In this case a steel tank - Transmission Main from source to storage - Distribution System including domestic, commercial and fire flows #commercial #distribution #fire_protection #industrial #piping #pumps #recreational #residential #schematic #source #storage #system #transmission #water
