Speaker Enclosure for Tectonic Elements 3-1/2" BMR by Emotiva
by Thingiverse
Last crawled date: 4 years ago
I made a quick baffle-cutout alteration of my Dayton RS100 enclosure to allow use of the more economical (my go-to small project driver) Tectonic Elements TEBM65C20F-8 3-1/2" BMR. Note, the volume and port designs were not optimized for this remix, but these drivers seem to be easy to please. Off-axis performance is especially good compared to the other small full-range drivers I've used.
March 12, 2021: Added sealed version.
March 12, 2021: Added sealed version.
