File: Sine Plate Setup.stl
Name: Sine Plate Setup
PLA Material: 115.12 grams ( 0.254 lbs) Infill = 10%
Size: 101.6 mm (4) x 98.61 mm (3.882) x 98.61 mm (3.882)
Resolution: 0.20mm
Layers: 499 layers Rafts: Yes Supports: No
Print Time: 6 hr 55 min
Function: If you print this 1:1 then you will have a setup tool for a standard 5 center to center sine plate that replaces six different guage block setups. Other possible scales are shown below: If you download the sine plate or sine plate assembly then it should be printed at the same scale.
