gotway mcm5 body reinforcement
by Thingiverse
Last crawled date: 5 years, 8 months ago
a preventive measure. dont use it if yours already cracked
you will need lots of grinding on a flat surface to make it fit snugly
mirror mcm2 and mcm3 for the other side
part mcm2 needs to be cut from the speaker's side or not used at all
sidepanel_shim must be installed if you want to use the screw hole under the logo (use a brass m5 (or m4. i dont know what size the original was) threaded insert first in the inner shell)
grind down some metal from the lower bolts' heads
i printed it in ABS and used ABS slurry as glue
use replacement logos from herehttps://www.thingiverse.com/thing:4214141
