Hi !
This is a request by Crisiinvolo. (cover picture is his print and paint job)
I modelled it from scratch with CREO, based on pictures
I tried to model every little detail I could see :-)
It was really fun to make
I'm not 100% sure about dimensions and proportions, but it should be OK for 28mm
everything should be easily printable, as oriented, with a few support where necessary
Print list :
6x foot
2x ark_side + 2x mirror
2x ark_center_V3
1x base
1x tray
2x claw
1x lower pivot
1x upper pivot
1x axis
1x lock
1x cristal - could be probably printed hollow with clear green filament ?
1x pedestal A &B
1x cristal top A&B
2x cristal lateral support + 2x mirrored
2x cristal side support + 2x mirrored
2x ark tip
6x pylon arm
2x lateral tube
Assembly with 6mm and 4mm rod
edit 15/10 : a little part was missing in the ark_center part. Uploaded a V2, and the missing part for those who already printed the V1
edit 16/10/2017 : the link parts between base and ark are online!
assembly instructions : DONT GLUE IT
insert the lower part under the base
insert the pivot part above the base
insert the pivot inside
insert one claw on each side of the ark, and insert the whole on the base
Lock the assembly with the little lock. If necessary, adjust the height of the lock
edit 17/10/2017 added cristal and his pedestal and supports
edit 19/10/2017 : finished, all parts are online !!
edit 24/12/2017 : added pylon center V3 (thanks 0000xl for the detail)
edit 11/02/2018 :new version for pylon center and ark_side with 4mm holes for alignment pins
