THE SAME AS THIS THING BUT WITHOUT INTEGRATED GPS MOUNT : https://www.thingiverse.com/thing:4661078
AMOVIBLE GPS MOUNT (BN220) : https://www.thingiverse.com/thing:4666419
I created a new canopy for the Eachine Tyro79 which allow to :
Put the battery on the top,
Put a Vifly Finder V2 (or other autonomous buzzer) inside with button access,
Put a SMA antenna (uFL antenna still possible, as used on the pictures),
Use a different brand camera and adjust the angle and position.
Une a different brand battery strap (20mm wide).
DISCLAMER : This canopy isn't intended to be pretty, but to maximize the available space inside.
Total weight without battery : approx. 176g (245g with a Tattu 4S 650mah).
You have to provide :
4 M2 nuts (for the underside)
4 M210mm screws (for the underside)
5 M212mm or 10mm screws (for the side)
2 M2*4mm screws (for the camera,I used the original eachine screws)
Nuts have to be put in their smallest width with force.
I still haven't fly it so I can't tell you anything about possible vibrations, solidity, or other possible issues. I'll update the post ASAP.
Don't hesitate to suggest improvements and let me know about the issues encountered.
AMOVIBLE GPS MOUNT (BN220) : https://www.thingiverse.com/thing:4666419
I created a new canopy for the Eachine Tyro79 which allow to :
Put the battery on the top,
Put a Vifly Finder V2 (or other autonomous buzzer) inside with button access,
Put a SMA antenna (uFL antenna still possible, as used on the pictures),
Use a different brand camera and adjust the angle and position.
Une a different brand battery strap (20mm wide).
DISCLAMER : This canopy isn't intended to be pretty, but to maximize the available space inside.
Total weight without battery : approx. 176g (245g with a Tattu 4S 650mah).
You have to provide :
4 M2 nuts (for the underside)
4 M210mm screws (for the underside)
5 M212mm or 10mm screws (for the side)
2 M2*4mm screws (for the camera,I used the original eachine screws)
Nuts have to be put in their smallest width with force.
I still haven't fly it so I can't tell you anything about possible vibrations, solidity, or other possible issues. I'll update the post ASAP.
Don't hesitate to suggest improvements and let me know about the issues encountered.
